Cutting Edge Kit for 9-1/2′ MVP – Part #66420

This cutting edge fits the following model(s): 9-1/2′ MVP®

This is the standard cutting edge for this plow

This kit includes both cutting edge sides, the center edge kit, and all required mounting hardware.

Please verify cutting edge dimensions in the table in the description tab below.

$530.86

1 in stock (can be backordered)

-

Cutting Edge Dimension Information (Dimensions listed for single side)
Length Height Thickness # of Holes Hole Size Bolt Size Bolt Type & Grade Hole Type Top to Hole (“) Edge to Center of (“)
1st Hole 2nd hole 3rd Hole
55 7/8″ 6″ 1/2″ 6 9/16″ 1/2-13 x 2 Carriage Bolt Grade 8 Square Punch 1 3/8″ 2″ 8″ 22 1/8″
Cutting Edge Dimension Information
Length 55 7/8″
Height 6″
Thickness 1/2″
# of Holes 6
Hole Size 9/16″
Bolt Size 1/2-13 x 2
Bolt Type & Grade Carriage Bolt Grade 8
Hole Type Square Punch
Top to Hole (“) 1 3/8″
Edge to Center of (“)
1st Hole 2″
2nd hole 8″
3rd Hole 22 1/8″
Weight 92.88 lbs
Dimensions 55.8750 × 1.0000 × 6.0000 in
Cutting Edge Length

55 7/8"

Cutting Edge Material

Steel

Blade Style

V-Plow
