Cutting Edge Kit for HTS - Part #69499

Cutting Edge Kit for HTS – Part #69499

(2 customer reviews)

This cutting edge fits the following model(s): HTS™

This is the standard cutting edge for this plow

This kit includes the cutting edge and all required mounting hardware.

Please verify cutting edge dimensions in the table in the description tab below.

Original price was: $191.00.Current price is: $181.45.

1 in stock

-

Cutting Edge Dimension Information
Length Height Thickness # of Holes Hole Size Bolt Size Bolt Type & Grade Hole Type Top to Hole (“) Edge to Center of (“)
1st Hole 2nd hole 3rd Hole
90″ 6″ 5/16″ 10 11/16″ x 1 3/8″ 5/8-11 x 2 Carriage Bolt Grade 5 Slotted 1 1/8″ 2 1/2″ 5 1/2″ 12 1/2″
Cutting Edge Dimension Information
Length 90″
Height 6″
Thickness 5/16″
# of Holes 10
Hole Size 11/16″ x 1 3/8″
Bolt Size 5/8-11 x 2
Bolt Type & Grade Carriage Bolt Grade 5
Hole Type Slotted
Top to Hole (“) 1 1/8″
Edge to Center of (“)
1st Hole 2 1/2″
2nd hole 5 1/2″
3rd Hole 12 1/2″
