The genuine Western 94536 Flange Bearing serves as a high-capacity mechanical support component engineered to stabilize the rotational tracking of the main conveyor shaft. Measuring exactly 1.125 inches (1-1/8″) in inner diameter, this factory-original bearing features a robust 2-bolt housing pattern with a 4-5/8 inch bolt hole center-to-center mounting distance. Commercial fleet mechanics install this heavy-duty flange bearing on the conveyor drive or idler shaft assemblies of Western Tornado, Striker, and Ice Breaker series hopper spreaders to replace worn, grinding, or seized bearings before extreme winter ice storms demand high-volume de-icing dispatch.
This factory-authorized bearing assembly is engineered with a specialized sealed insert casing to withstand continuous contact with highly abrasive bulk de-icing materials. The heavy-duty cast housing mounts directly to the outer spreader framework, maintaining precise shaft alignment under the extreme down-pressure loads of multi-ton salt or sand capacities. The integrated grease zerk allows for routine preventative lubrication maintenance, purging corrosive moisture, salt brine, and fine road debris out of the internal ball path to eliminate premature mechanical drag.
For professional winter maintenance contractors and municipal fleet managers, executing a proactive replacement on sloppy or rough-turning flange bearings avoids severe drivetrain torque damage and unexpected field breakdowns. This durable 2-bolt bearing serves as a direct drop-in replacement across Douglas Dynamics family hopper spreaders, including Fisher Polycaster and SnowEx Renegade poly and stainless steel V-box configurations. Integrating this authentic factory component ensures your conveyor pintle chain or belt tracks cleanly, preserving the service life of your electric drive motors and gearboxes.
Benefits of the Western 94536 Flange Bearing
-
Genuine OEM Direct Fit: Designed and balanced precisely to factory dimensional blueprints for Western Tornado, Striker, and Ice Breaker hopper models.
-
Sealed Casting Protection: Deep-groove ball bearing is housed in a rugged cast structure with sealed guards to block corrosive salt and moisture infiltration.
-
Standard 2-Bolt Mounting: Formed with a 1-1/8″ inner diameter bore and standard 4-5/8″ center-to-center bolt tracks for fast, direct field installation.
-
Integrated Grease Fitting: Features an accessible lubrication port to easily flush away operational salt contamination during routine maintenance.
-
Shields Upstream Drivetrains: Eliminates shaft wobbling and rotational friction to lower the workload on electric drive motors and expensive gearboxes.
Additional Info and Common Related Parts
| Part Number | Item Name | Technical Role |
| 65909 | Drive Sprocket (6-Tooth) | Cast iron 1-1/8″ ID pintle sprocket interfaces directly with the drive shaft to pull the conveyor chain forward. |
| 68474 | Conveyor Chain 123 Link | Heavy-duty V-box drag chain moves bulk salt from the hopper vault back to the spinner chute. |
| 95567 | Tornado Gear Case 20:1 | High-torque reduction gearbox drives the primary conveyor shaft to control material flow rates. |
| 94953 | Conveyor Drive Spreader Bearing Kit | Multi-component hardware overhaul pack containing matching bearings and seals for complete shaft servicing. |
Always refer to your Western Spreader’s documentation and equipment-specific installation instructions to confirm compatibility and proper installation procedures.
